Markilux 8000 Curved Front System

Conservatory Awnings

The markilux conservatory model for that all round good feeling atmosphere.

Everything that makes your favourite place in the conservatory is possible from a simple “bend” to vertical shade.

Totally logical. Typically markilux.

Construction and design:
This markilux can do everything and has everything to offer that distinguishes the markilux 8000. Additionally, the awning cover is guided over the curved front via the guide rollers:


Angle of curved front

Cover guide rollers

up to 30°

1

31° to 60°

2

61° to 85°

3

Cassette / Mounting:
This supports your markilux and is particularly stable. Awnings up to approx. 35 m² are available as individual systems. 700 cm wide systems are coupled together, however they have a continuous profile for easy, individual mounting. Pre-assembly and the patented clip-on mountings make this particularly easy.

Cover:
All markilux awning cloths can be used. We particularly recommend: markilux transolair and Perfotex with the practical hole-weaving technique.

Drop:
The awning is a maximum 700 cm long. The track profiles can jut out over the edge of the shade area by up to 100 cm.

Operation:
The electric motor is standard. Where there are several awning areas, several separately controlled motors are necessary amongst other things.


Number of areas

Number of motors

2

1

2

2*

3

2*

Mechanism:
Two optimised gas primed pistons create a particularly high cover tension independently from one another. An extra strong front profile minimises the cloth and profile droop.

Special features:
The own weight of the cloth means that droop is possible that will increase when wet. For this reason a cover support tube is part of larger systems. We also recommend a cover support tube where the awning has a flat pitch.

Special Equipment

  • Sun & Wind Sensor
  • Motor drives and remote control operation
